Custom AI Chips

Chip Solutions Catalog

↓ Blackhole™ Series - High-Performance AI Computing

Blackhole™ p100a

The Blackhole™ p100a features Tenstorrent’s high performance Blackhole™ Tensix Processor, with 120 Tensix Cores and 28 GB of GDDR6, operating at up to 300W in an active-cooled form factor geared for desktop workstations. p100a is supported by Tenstorrent’s fully open source software stack, granting developers full access to the metal.

Software Capabilities

CPU – x86_64 architecture*
Motherboard – PCI Express 5.0 x16 slot, dual-slot width**
Memory – 64 GB
Storage – 100 GB (> 2 TB recommended)
Power Connectors – 12V-2x6
Total Board Power – Up to 300W
Power Supply – ATX 3.1 Certified
Operating Temperature Range (Die) – 0C - 95C
Operating System – Ubuntu version 22.04 (Jammy Jellyfish)

Blackhole™ p150a

The Blackhole™ p150a features Tenstorrent’s high performance Blackhole™ Tensix Processor, with 140 Tensix Cores and 32 GB of GDDR6, operating at up to 300W in an active-cooled form factor geared for desktop workstations.

Software Capabilities

CPU – x86_64 architecture*
Motherboard – PCI Express 5.0 x16 slot, dual-slot width**
Memory – 64 GB
Storage – 100 GB (> 2 TB recommended)
Power Connectors – 12V-2x6
Total Board Power – Up to 300W
Power Supply – ATX 3.1 Certified or better
Operating Temperature Range (Die) – 0C - 95C
Operating System – Ubuntu version 22.04 (Jammy Jellyfish)

↓ Wormhole™ Series - Cost-Effective AI Solutions

Wormhole™ n150d

Wormhole™ n150d features Tenstorrent’s flexible, scalable Wormhole™ Tensix Processor operating at up to 160W, offering superior performance for cost compared to traditional GPUs and broad data precision format support. The processor can network into a multichip mesh for workstations and servers (such as Galaxy) and is supported by Tenstorrent’s fully open source software stack, granting developers full access to the metal. n150d includes a 2.5-slot active cooling solution.

Software Capabilities

CPU – x86_64 architecture
Motherboard – PCI Express 4.0 x16 slot, Triple-slot width
Memory – 64 GB
Storage – 100 GB (≥2TB recommended)
Power Connectors – 4+4-pin EPS12V
Total Board Power – Up to 160W
Operating Temperature Range (Die) – 0C - 75C
Operating System – Ubuntu version 22.04 (Jammy Jellyfish)**
Internet Connection – Required for driver and stack installation

Wormhole™ n300d

Wormhole™ n300d features two of Tenstorrent’s flexible, scalable Wormhole™ Tensix Processors operating at up to 300W, offering superior performance for cost compared to traditional GPUs and broad data precision format support. The processor can network into a multichip mesh for workstations and servers (such as Galaxy) and is supported by Tenstorrent’s fully open source software stack, granting developers full access to the metal. n300d includes a 2.5-slot active cooling solution.

Software Capabilities

CPU – x86_64 architecture
Motherboard – PCI Express 4.0 x16 slot, Triple-slot width
Memory – 64 GB
Storage – 100 GB (≥2TB recommended)
Power Connectors – 4+4-pin EPS12V
Total Board Power – Up to 300W
Operating Temperature Range (Die) –0C - 75C
Operating System – Ubuntu version 22.04 (Jammy Jellyfish)
Internet Connection – Required for driver and stack installation

Ready to Own Your AI Data Now?

Talk to our team about your infrastructure needs – from a single deploymentto a national sovereign AI program.

Thank you! Your submission has been received!

Oops! Something went wrong while submitting the form.

Or reach us directly via email – contact@qblocks.ai

Frequently Asked Questions

How does this compare to NVIDIA or AMD GPUs?

Comparable performance with open architecture, no licensing costs, and complete hardware-levelaccess. Better choice for applications requiring deep optimization or avoiding vendor lock-in.

When should I choose Blackhole over Wormhole?

Blackhole p100a (120 cores, 28GB) or p150a (140 cores, 32GB) for high-performance: Level 4-5autonomous driving, drone swarms, aerospace AI. Wormhole n150d (160W single processor) or n300d(300W dual processor) for cost-effective applications: infotainment, ADAS, edge computing.

Can I start with Wormhole and upgrade to Blackhole later?

Yes. Both use the same software stack. Code developed on Wormhole n150d/n300d runs onBlackhole p100a/p150a without rewrites. The p150a also supports multi-card linking for memorypooling and infinite scalability.

How long does integration take?

Typical timeline is 3-6 months from requirements to production deployment.

What memory configurations are available?

Blackhole p100a offers 28GB GDDR6, p150a offers 32GB GDDR6. The p150a supports multi-cardlinking to pool memory across cards for larger models. Wormhole series configurations vary byapplication - contact us for specific requirements.

What are the costs compared to proprietary GPUs?

Typically 40-60% less when factoring in hardware costs, zero licensing fees, and no vendorlock-in. Contact us for detailed quotes based on your configuration.
